Topcon HiPer V - Data and Power Ports

Getting Acquainted
DataandPowerPorts
15
P/N:1001608‐01
Data and Power Ports
TheHiPerVhasthetwoportsdescribedbelow:
• Serial‐rimmedinblack;usedforcommunicationbetweenthereceiverandanexternaldevice.Thebodyofthe
connectoronthecorrespondingcableisblack.
• Power‐rimmedinred;usedtoconnectthereceivertoanexternalpowersource.Thebodyoftheconnectoronthe
correspondingcableisred.
Figure5:HiPerVPorts
Antenna
Port
Power
Port
Serial
Port
Modem
Antenna
Port
