Connector Specifications
Thereceiverhas3externalconnectors;oneUHF/915+radiomodemorcellularantennaconnector.
UHF Radio Modem Connector
Reverse TNC Connector
Table13.UHFModemConnectorSpecifications
Modem Type Signal Type Dir Details
UHF BNC Modem I/O I/O RF/GSM output from
modem antenna
Table14.ReverseTNCConnectorSpecifications
Modem Type Signal Type Dir Details
915+ Reverse TNC Modem I/O I/O RF/GSM output from
modem antenna
