Topcon HiPer V - Recording Data

Collecting Data
RecordingData
57
P/N:1001608‐01
Recording Data
YoucanlograwGNSSdatatothereceiver’smemorycardandusetheTopconReceiverUtility(TRU)or MAGNETOffice™software
todownloadthefi lestoacomputer.
Tostartorstoprecordingdatatothereceiver,youcanusetheLEDdisplaypanelorTRU.
1. PressthePowerbuttontoturnonthereceiver.
2. WaitfortheSTATLEDtoindicatesatellites arebeingtracked.TheSTATLEDblinksgreenforGPSsatellitesandamber
forGLONASS satellites. A short red blink indicates the receiver has not solved a position. Five or more satellites
provide optimal positioning.
3. PressthePOWERbuttonthreetimeswithintwosecondstobeginrecording.YoucanalsoselectFile
Explorer
LogsStartinTRUtobeginrecordingdata.
4. MakesuretheREClightisblinkinggreen.Thisindicatesthatafilehasopenedanddatacollectionhasstarted.The
RECLEDblinkseachtimedataissavedtomemory.
5. Whenyouhavefinishedrecording,pressthePOWERbuttonthreetimes,and
makesuretheRECLEDisdark.Youcan
alsoselectFileExplorerLogsStopinTRUtoenddatarecording.
6. Toturnoffthereceiver,pressandholdthePOWERbuttonfor3to10secondsuntilallLEDsturndarkandtheBAT
LEDissolidred.
YoucanalsologdatausingMAGNETFieldsoftware.
