Topcon HiPer V - HSPA Module Specifications

Specifications
OptionalCellularModuleDetails
83
P/N:1001608‐01
a.TopconGNSSreceiversequippedwithintegratedC24wirelessmodulesareauthorizedtooperateintheUSonlyontheVerizon
TM

wirelessnetwork.
HSPA Module Specifications
Table 10. Cellular Module Specifications
General (3.5G Wireless Module Quad-band GSM and UMTS/HSPA)
Supported bands GSM 850/900/1800/1900 MHz
UMTS/HSPA 850/1900/2100 MHz
TX power UMTS/HSPA - Class 3 (0.25 Watt)
GSM 850/900 MHz – Class 4 (2 Watt)
GSM 1800/1900 MHz – Class 1 (1 Watt)
EDGE 850/900 MHz – Class E2 (0.5 Watt)
EDGE 1800/1900 MHz – Class E2 (0.4 Watt)
Data UMTS/HSDPA/HSUPA 3GPP, Release 6
GSM/GPRS 3GPP, Release 9
Max uplink 5.76 Mbps, max downlink 7.2 Mbps
EDGE, Multi-Slot class 12
CSD, Max BR 14.4 Kbps GSM, Max BR 14.4 Kbps UMTS
AT command Set GSM 07.05, 07.07
