Specifications
GeneralDe tails
72
P/N:1001608‐01
Port specifications COM1: 4,800 to 115,200 bps (RS Level)
115,200 bps (default)
Bluetooth: 115,200 bps (SPP/Single Channel mode)
Modem Antenna BNC or reverse polarity TNC (depending on modem type)
NMEA
NMEA version Ver. 2.1, 2.2, 2.3, 3.0
Messages GGA, GLL, GNS, GRS, GSA, GST, GSV, HDT, RMC, VTG, ZDA, ROT, GMP
Output interval Up to 20Hz
DGPS
Correction format RTCM SC104 Ver 2.1, 2.2, 2.3, 3.0, 3.1
RTCM message
type
1, 3, 9, 31, 32, 34; user selectable
Process interval Up to 20Hz
Output interval for
RTCM correction
data
Up to 20Hz
Elevation mask
0 to 90 degrees (independent of data logging
)
Table4.ReceiverGeneralSpecifications(Continued)
