Specifications
GPSBoardDetails
77
P/N:1001608‐01
PLL/DLL/QLL Bandwidth, order, adjustable
Smoothing interval Code and Carrier
WAAS/EGNOS/
MSAS
Optional
Data Features
Formats TPS, NMEA, RTCM, CMR/CMR+
Features Up to 20 Hz update rate for real time position and raw data (code and carrier)
10cm code phase and 0.1mm carrier phase precision
RTCM SC104 version 2.1, 2.2, 2.3, 3.0, and 3.1 I/O
Multiple Base RTCM
Geoid and Magnetic Variation models
Different DATUMs support
Output of grid coordinates
CMR and CMR+ support
Memory
Internal Memory SD/SDHC card, removable
Capacity Dependent on capacity of the installed SD/SDHC card
Logging Interval 0.05 to 86,400 seconds, depending on purchased options
a.VanguardASICincludestwodedicatedchannelsforL‐Bandsignaltracking.ThereceiverdoesnotsupportL‐Bandsignaltracking.
Table5.GPSBoardSpecifications(Continued)
