Grading Applications
Motorgrader System Five Operator’s Manual
5-18
Begin grading, then immediately switch to automatic control. You can
make grade adjustments using the Smart Knob, which will keep your
hands on the controls. You may want to dial in a small amount of cut
as you make this first "pioneering" pass. Depending upon the material
conditions and amount of cut along the road.
Figure 5-22.
WINDROW
VIEW FROM BEHIND GRADER
2.0%
SLOPE
1.70
F
T
CONTROL MODE
G
A
INS
E
T/+/
—
/T
R
IMM
E
NU
2.0%
-
CUT GRADE 1.70' BELOW
THE SONIC STRINGLINE
