P/N 7010-0344
Chapter 2
2-1
Operation
This chapter reviews System Five's components and explains the
function of each.
NOTICE
NOTICE
When operating in rainy weather or in wet conditions, the
Control Box, Sonic Tracker II's, and cables must be
thoroughly dried BEFORE placing them in the Carrying
Case at the end of the day.
Any moisture left on the Control Box, Sonic Tracker II's and/
or cables when being put into the Carrying Case can
cause condensation on the inside of the components
which may severely affect accurate operation during the
next grading session.
Control Box
The Control Box is the main operator control interface for System
Five. It has several purposes. One is to inform the operator of the
system's performance. It also receives information from the sensors,
processes the information, and sends out correction signals to the
grader's hydraulic system when required.
