P/N 7010-0344
Chapter 4
4-1
Getting Ready to Grade
Control Box Setup
To prevent theft or vandalism, the Control Box has been designed for
quick removal at the end of the day. To install the Control Box, just
bolt it on with the hand knob and connect the two quick-disconnect
electrical connectors.
Figure 4-1.
When you power up System Five, it will automatically come on to
Control Mode with the settings just as you had them the last time the
box was used. The Slope Calibration and Elevation Reference Setting
are stored in the Control Box. Except for possible cutting edge wear
and changes in Sonic Tracker or Laser Trackerjack set up, you may
not need to make any calibration or adjustments for many weeks or
months. In most cases, you can turn on the box and begin grading.
S
ystem
F
ive
