P/N 7010-0344
Chapter 3
3-1
Calibration
Figure 3-1.
Why do you need to calibrate?
Although System Five does not usually require maintenance or
adjustment, the grader it is attached to does. All the moving parts on
your grader wear at different rates. In order for System Five to work
correctly, it has to be "told" what changes have occurred on your
grader. All the Calibration Settings are stored in the Control Box
memory. The Control Box will not "loose" the Calibration Settings
when turned off or stored for long periods.
There are 6 calibration selections: Rotation Sensor, Mainfall Sensor,
Blade Slope Sensor, Blade Wear (trim), Adjust Valve Offsets,
External Switch.
Figure 3-2.
MACHINE SETUP
E
NT
E
R
E
XIT
CALIBRATION
SET POINTS
MEASUREMENT UNIT
CHECK HOURMETERS
ADJUST LED BRIGHTNESS
SYSTEM TEST
BEEPER
