System Overview
Motorgrader System Five Operator’s Manual
1-10
Hydraulic Manifold Assembly
The Hydraulic Manifold Assembly is connected into the grader blade
lift cylinders. It acts like the manual valves the operator controls by
hand, automatically raising or lowering the blade to produce desired
grade.
The Hydraulic Manifold Assembly is a sealed unit and contains no
adjustments. Once attached to the machine, it should not be removed.
Figure 1-9.
