Grading Applications
Motorgrader System Five Operator’s Manual
5-26
Press the red buttons on the Smart Knobs to get the Sonic Tracker to
On-Grade.
Since the Tracker is tracking the ground sloping down the opposite
side, the reference number will not be 0.00.
Switch to Automatic Control and continue grading. Verify the grade
and make small adjustments as necessary.
Figure 5-35.
C
L
0.12
F
T
CONTROL MODE
G
A
IN/
+
/
—
/T
R
IMM
E
NU
2.0%
+
S
E
T
S
onic
T
racker
II
S
onic
T
racker
II
