System Overview
Motorgrader System Five Operator’s Manual
1-2
Figure 1-1.
1. Control Box 2. Laser Tracker & Trackerjack 3. Smart Knobs
TM
4. Sonic Tracker II
TM
5. Slope Sensor 6. Rotation Sensor 7. Manifold Sensor 8. Hydraulic Manifold Assembly
1
2
3
5
6
4
7
8
