Sonic Tracker Setup
P/N 7010-0344
4-5
The closest the Tracker can be set to the grade reference is 14 inches.
Figure 4-5.
The farthest the Tracker can be set from the grade reference is 55
inches.
Figure 4-6.
14.0"
MINIMUM
DISTANCE
S onic T racker II
T
S onic T racker II
T
55.0"
MAXIMUM
DISTANCE
