Setting the Reference Number
P/N 7010-0344
4-11
When setting the Tracker reference number, be aware of cutting edge
wear common at the edges of the blade. Setting to 0.00, with the tip of
the blade on the ground, would cause the blade to undercut farther in
from the edge. For best results, switch to Automatic and grade a short
pass. Look about 18 inches in from the end of the blade to verify
whether the cutting edge is matching. Make grade adjustments as
needed to get the cutting edge to match perfectly, and then reset the
number to 0.00. It is usually better to set the blade to .01 foot or .02
foot high.
Figure 4-16.
S
onic
T
racker
II
T
S
onic
T
racker
II
T
Error Induced
by Cutting
Edge Wear
Match Surface 18.0" in from Edge
