Toro 31598 - Remove Side Deck Shipping Strap and Brace; Lower Front Deck Winglets

1
RemoveSideDeckShipping
StrapandBrace
NoPartsRequired
Procedure
Removethestrapandbracesecuringthesidedecksfor
shipping.
2
LowerFrontDeckWinglets
Partsneededforthisprocedure:
1DeckcoverR.H.
1DeckcoverL.H.
2V-Belt
Procedure
1.Removethenutssecuringthefrontandrearstop
boltstotherightwingletdeckmounts(Figure3).
2.Whilesupportingtherightwinglet,removethefront
andrearstopboltsfromthedeckmounts(
Figure3).
Leavetheeccentricspositionedbetweenthedeck
mounts.
3.Lowerthewinglettotheoperatingposition.
Figure3
1.Winglet4.Eccentric
2.Hingepin5.Upperhole
3.Stopbolt
6.Deckmounts
4.Installthefrontandrearstopboltsthroughthe
uppermountingholesandeccentrics.Makesurethe
stopboltengagesthetabonthehingepin.
5.Installthenutssecuringthestopboltsbutdonot
tightenatthistime.
6.Repeattheprocedureonleftwinglet.
Figure4
1.Winglet4.Eccentric
2.Hingepin5.Lowerhole
3.Bolt
16
