FuelSystem
Maintenance
ServicingtheFuelSystem
DANGER
Undercertainconditions,dieselfuelandfuel
vaporsarehighlyammableandexplosive.Are
orexplosionfromfuelcanburnyouandothersand
cancausepropertydamage.
•Useafunnelandllthefueltankoutdoors,in
anopenarea,whentheengineisoffandiscold.
Wipeupanyfuelthatspills.
•Donotllthefueltankcompletelyfull.Addfuel
tothefueltankuntilthelevelis1inch(25mm)
belowthebottomofthellerneck.Thisempty
spaceinthetankallowsthefueltoexpand.
•Neversmokewhenhandlingfuel,andstayaway
fromanopenameorwherefuelfumesmaybe
ignitedbyaspark.
•Storefuelinaclean,safety-approvedcontainer
andkeepthecapinplace.
FuelTank
ServiceInterval:Every1,000hours—Drainandclean
thefueltank.
Drainandcleanthefueltankevery1000hours.
Also,drainandcleanthetankiffuelsystembecomes
contaminatedorifthemachinewillbestoredforan
extendedperiodoftime.Usecleanfueltoushout
thetank.
FuelLinesandConnections
ServiceInterval:Every500hours—Inspectthefuel
linesandconnections.
Checkthefuellinesandconnectionsevery500hours
oryearly,whichevercomesrst.Inspectthemfor
deterioration,damage,orlooseconnections.
ServicingtheWaterSeparator
ServiceInterval:Beforeeachuseordaily—Drainthe
waterseparator
Every500hours—Replacethe
fuel/waterseparatorelement.
DrainingtheWaterSeparator
1.Placeacleancontainerunderthewaterseparator
(Figure62).
2.Openthedrainplugandoperatethepumptodrain
offcontaminates(Figure62).
Figure62
1.Waterseparatorlter
canister
4.Flowcheckvalve
2.Primingpump5.Ventplug
3.Drainplug
3.Closethedrainplug.
ReplacingtheFuelFilterElement
1.Placeacleancontainerunderthewaterseparator.
2.Drainsomefuelbylooseningtheventplugand
openingthedrainplug(Figure62).
3.Disconnectthewatersensor(electricalconnector)
fromthebottomofthewaterseparator
4.Cleantheareawherethelterelementmountsto
thehead.
5.Removethelterelementandbowl.Removethe
elementfromthebowlandcleanthemounting
surface.
6.CleantheO-ringglandonthebowl.
7.Applyacoatingofcleanfuelormotoroiltothenew
O-ringandelementseal.
8.Spinthebowlontothenewelementandthenspin
thembothontothelterheadbyhandonly.Donot
usetools.
9.Closethedrainplug.
