Toro 31598 - Changing the Hydraulic Fluid and Filters

Figure89
1.Yellowplunger2.Redzone
ChangingtheHydraulicFluid
andFilters
ServiceInterval:Every1,000hours—Changethe
hydraulicuidandlters.
Changethe2hydraulicltersandthehydraulicuid
afterevery1000operatinghours,innormaloperating
conditions.Iftheuidbecomescontaminated,contact
yourlocalTorodistributorbecausethesystemmustbe
ushed.Contaminateduidlooksmilkyorblackwhen
comparedtocleanoil.
UseTororeplacementlters(PartNo.86–6110forthe
leftsideofthemachineand75-1310fortherightside
ofthemachine).
Important:Useofanyotherltermayvoidthe
warrantyonsomecomponents.
1.Positionthemachineonalevelsurface,lowerthe
cuttingunits,stoptheengine,engagetheparking
brakes,andremovetheignitionkey.
2.Placealargedrainpanunderthehydraulicuidtank.
3.Removethedrainplug(
Figure90)fromthebottom
ofthetankandletthehydraulicuidowintothe
pan.Installthedrainplugwhenthehydraulicuid
stopsdraining.
Figure90
1.Hydrauliclter
3.Hydraulictankdrainplug
2.Hydrauliclter
4.Cleantheareaaroundtheltermountingareas.
Placeadrainpanunderthelterandremovethe
lter(Figure90).
5.Lubricatethenewltergasketandllthelterwith
hydraulicuid.
6.Ensurethattheltermountingareaisclean.Screw
theltersonuntilthegasketscontactsthemounting
plates;thentightenthelteranadditional1/2turn.
7.Fillthereservoirwithhydraulicuid;referto
CheckingtheHydraulicFluid.
60
