Toro 31598 - Level Front Center Deck; Level Winglet Decks to Front Center Deck

7.Installthewingletbeltsasfollows:
•Startthebeltaroundthewingletspindlepulley
andthefrontdeckspindlepulley(Figure5).
•Usingaratchetwrenchorsimilartool,movethe
idlerpulleyawayfromthepulleys(
Figure5).
•Routethebeltaroundthewingletspindlepulley
andtheupperspindlepulleyonthefrontdeck.
•Releasetheidlerpulleytoputtensiononthebelt.
Figure5
1.Wingletspindlepulley3.Idlerpulleyassembly
2.Frontdeckspindlepulley
8.Installthewingletdeckcoverandsecurewithrubber
latch(Figure6).
Note:Makesuretoslidethecoverunderthefront
centerdeckcovertabsbeforeinsertingitontothe
mountinghooksandpost.
9.Repeattheprocedureontheotherwinglet.
Figure6
1.Cover
3.Frontcenterdeckcover
tabs
2.Rubberlatch4.Mounthooks
3
LevelFrontCenterDeck
NoPartsRequired
Procedure
RefertoAdjustingtheHeight-of-CutinOperation.
1.Rotatebladeoneachouterspindleuntiltheends
faceforwardandbackward.
2.Measurefromtheoortothefronttipoftheblade.
Adjust1/8inchshimsonfrontcastorfork(s)to
matchdesiredheightofcut.
3.Rotatetheblades180°andnowmeasurefromthe
oortothe(rearfacing)tipoftheblade.
4.Loosenthelowerjamnutsontheheight-of-cut
chainU-bolt.
5.Adjustthenutstoraiseorlowertherearofthe
cuttingunitsothatthefrontandrearbladetipshave
thesamemeasurement.Tightenthejamnuts.
6.Proceedtoprocedure4andlevelthewingletdecks
tothefrontcenterdeck.
4
LevelWingletDeckstoFront
CenterDeck
NoPartsRequired
Procedure
Levelthewingletdeckstothefrontdeckasfollows:
•Rotatethebladeoneachwingletsothatitpoints
sidetoside.
•Loosentheboltsandnutssecuringthetwoeccentric
spacerstothewinglets(
Figure7).
17
