ElectricalSystem

Maintenance

WARNING

Ifinstallinganauxiliaryaccessorytothemachine,

theonlyapprovedlocationstosourcepowerare

thetractionunitfuseblock(

Figure68)orthecab

fuseblock(Figure70).Amaximumof10ampsis

availablefromeitherlocation.Contactyourlocal

Torodistributorforassistance.

Note:Makesurethekeyisoffandremovedfromthe

switchbeforeremovingfuses.

Fuses

Thetractionunitfuses(Figure68)arelocatedinthe

powercenterconsole(Figure67).

Figure65

Figure66

Figure67

1.Powercenterconsole2.Knob

Figure68

1.Fuses

3.Alternatepositivepostfor

jumpstarting

2.Fuses
