Toro 31598 - Premaintenance Procedures; Inner Wing Deck Covers

Premaintenance
Procedures
InnerWingDeckCovers
Removal
1.Lowerthewingdeckontoalevelsurface.
2.Disengagethecoverlatch.
3.Removetheboltsecuringthebeltcover,ifso
equipped.
4.Lifttherearandinsidecoveredgesoffthemounting
posts(
Figure46).
Figure46
1.Mountingposts
5.Whileliftingthecover,slideittowardthetraction
unit,approximately1inch,todisengagetheouter
coveredgefromthedeck(Figure47).
Figure47
1.Slidecoverinward
approximately1inch
2.Disengagethesecover
edges
6.Liftthefrontedge,guideitbetweentheliftarmand
therollertoremoveit(
Figure48).
Figure48
1.Slidecoveroutbetweenliftarmandroller
Installation
1.Lowerthewingdeckontoalevelsurface.
2.Slidethecoverintopositionbyguidingtherearedge
betweentheliftarmandroller.
3.Whileslidingthecoverawayfromthetractionunit,
guidetheoutsideedgeunderthefrontandrear
bracketsonthedeck.
4.Alignthedeckmountingpostswiththeholesinthe
coverandlowerthecoverintoposition.
5.Installtheboltsecuringthebeltcover,ifsoequipped.
6.Engagethedeckcoverlatch.
42
