Figure7
1.Winglet4.Eccentric
2.Hingepin5.Upperhole
3.Stopbolt
•Rotatetherear(closesttotractionunit)eccentric
untiltheoutsidebladetipisabout1/8inchhigher
thanthedesiredheightofcut(Figure7).
Note:Thereisanotchontheeccentrichexwhichis
180°fromthelobeontheeccentriccam(Figure8).
Usethenotchestoreferencethelocationofthe
lobeswhenadjustingtheeccentrics.
Figure8
1.Eccentricnotch
•Tightentheboltandnutforthiseccentricto110
ft-lb(149N-m).
•Adjusttheforwardeccentricuntilitjustmakes
contactwiththeinnerslotsurfaceofthewinglet
pivotbrackets.
•Tightentheboltandnutforthiseccentricto110
ft-lb(149N-m).
•Repeattheprocedureontheoppositewinglet.Refer
toAdjustingtheCuttingUnitPitchprocedurein
MowerMaintenance.
5
CheckingTirePressure
NoPartsRequired
Procedure
Checktheairpressureinallthetiresbeforeoperating
themachine.Thecorrectairpressureinthefronttires
is50psi(345kPa)andthereartiresis30psi(207kPa)
(Figure9).
Important:Maintainpressureinalltiresto
ensureagoodquality-of-cutandpropermachine
performance. Do not under -inate.
Figure9
6
CheckingFluidLevels
NoPartsRequired
Procedure
1.Checktheengineoillevelbeforestartingtheengine,
refertoCheckingtheEngineOilLevelinEngine
Maintenance.
