Toro 31598 - Replacing the Fuel Filter

10.Connectthewatersensor(electricalconnector)from
thebottomofthewaterseparator.
11.Withtheventplugstillloosened,operatetheprimer
pumpuntilfuelpurgesattheventplug.Close
theventplug,starttheengineandcheckforleaks.
Correctasnecessarywiththeengineoff.
ReplacingtheFuelFilter
ServiceInterval:Every500hours—Replacethefuel
lterelement
1.Cleantheareaaroundthefuellterhead(
Figure63).
Figure63
1.Fuellterhead
2.Filter
2.Removethelterandcleanthelterheadmounting
surface(Figure63).
3.Lubricatetheltergasketwithcleanlubricating
engineoil.RefertotheEngineOperator’s
Manual,includedwiththemachine,foradditional
information.
4.Installthedryltercanister,byhand,untilthegasket
contactsthelterhead,thenrotateitanadditional
1/2turn.
5.Loosenthebanjottingonthefuellterhousing
(
Figure64).
Figure64
1.Fuellter3.WaterSeparator
2.Banjotting
4.Primingpump
6.Operatethewaterseparatorprimingpumpuntila
solidstreamoffuelisdetectedatthebanjotting
(Figure64).
7.Tightenthefuellterbanjotting.
8.Pushdowntheprimingpumpandturnitclockwise
tosecure.
9.Starttheengineandcheckforfuelleaksaroundthe
lterhead.
