Lubrication

GreasingtheBearingsand

Bushings

ServiceInterval:Beforeeachuseordaily—Lubricate

castorarmbushings.

Every50hours—Lubricateallgrease

ttings.

Themachinehasgreasettingsthatmustbelubricated

regularlywithNo.2GeneralPurposeLithiumBase

Grease.Ifthemachineisoperatedundernormal

conditions,lubricateallbearingsandbushingsafter

every50hoursofoperationorimmediatelyafterevery

washing.

Note:Thecastorforkshaftbushingsmustbe

lubricatedbeforeeachuseordaily

Thegreasettinglocationsandquantitiesare:

TractionUnit

•Impactarms(2)(Figure49)

•FrontDeckLiftcylinderpivots(2)(

Figure49)

•SideDeckLiftcylinderpivots(2)(Figure49)

•Steeringcylinderballjoints(4)(Figure50)

•Tierodballjoints(2)(Figure50)

•Kingpinbushings(2)(Figure50)

•Rearaxlepivotbushing(1)(Figure51)

•Brakeshaftpivotbearings(1)(

Figure52)

Figure49
