Toro 31598 - Cleaning the Air Conditioning Coil; Cleaning the A;C Condenser Screen

CleaningtheAirConditioning
Coil
ServiceInterval:Every250hours—Cleantheair
conditioningcoil.(Cleanmore
frequentlyinextremelydustyordirty
conditions)
1.Stoptheengineandremovethekey.
2.Removethe(4)screwssecuringthefanandthe
condensercovertothefanmount(
Figure104).
3.Carefullyliftthefanoutofthecondensercover.
Figure104
1.Cabinroof
5.Fan
2.Condensercover6.Screw
3.Washer7.Airconditioningcondenser
4.Nut
4.Removethetwonutsandwasherssecuringthefront
ofthecondensercovertothecabroof(Figure104).
5.Unplugthefanwireconnectorslocatedbetweenthe
coverandroof.
6.Removethefanandthecover.
7.RemoveandcleantheA/CCondenserScreen.Refer
toCleaningtheA/CCondenserScreen.
8.Cleantheairconditioningcondenserthoroughly
withcompressedair(
Figure104).
9.ReplacetheA/CCondenserScreen.
10.Replacethecondensercoverandfan.Makesureto
connectthefanwiresbeforesecuringthecondenser
cover.
CleaningtheA/CCondenser
Screen
ServiceInterval:Every50hours—Cleantheair
conditioningscreen.(Cleanmore
frequentlyinextremelydustyordirty
conditions)
1.Stoptheengineandremovethekey.
2.Ontherearofthefanmount,rotatethelatchtothe
side(
Figure105).
Figure105
1.Latch
2.A/Cscreen
3.SlidetheA/Cscreenoutfromundertheair
conditioningcoil(Figure105).
4.Cleanthescreenthoroughlywithcompressedair
(Figure105).
5.Slidethescreenintothechannelsundertheair
conditioningcoilandrotatethelatchdownward.
68
