A.Allspringsmustbecompresseduntilthey
measure3.96cm(1.56inches).
B.Usethejamnuttocompressanyspring
thatmeasuregreaterthan3.96cm(1.56
inches).
g035648
Figure4
1.Section-hingespring3.Compressedspring
dimension—3.96cm(1.56
inches)
2.Jamnut
4.Repeattheprocedureforeachspringonboth
sectionhinges.
5.Movethesectionsintothetransport‘X’position.
SeeUsingtheBoom-TransportCradle(page
29)formoreinformation.
3
LearningMoreaboutYour
Product
Partsneededforthisprocedure:
1Ignitionkey
1
Operator'sManual
1Engineoperator'smanual
1
PartsCatalog
1
Operatortrainingmaterial
1Registrationcard
1
Pre-deliveryInspectionSheet
Procedure
1.Readthemanuals.
2.Viewtheoperatortrainingmaterial.
3.Completetheregistrationcardandreturnitto
Toro.
4.Storethedocumentationinasafeplace.
