Figure32
1.Greasetting(outboard
sideofthespraypump)
3.Frontofthemachine
2.Greasetting(bottom,
rearsideofthespray
pump)
4.Pumpgreaseintoeachremotegreasetting
(Figure32AandFigure32B).
5.Wipeofftheexcessgrease.
GreasingtheSection
Hinges
ServiceInterval:Every100hours
Important:Ifthesectionhingeiswashedwith
water,clearallwateranddebrisfromthehinge
assemblyandapplyfreshgrease.
GreaseType:No.2lithiumgrease
1.Wipethegreasettingscleansothatforeign
mattercannotbeforcedintothebearingor
bushing.
2.Pumpgreaseintothebearingorbushingat
eachtting(Figure33).
g002014
Figure33
1.Greasetting
3.Wipeoffexcessgrease.
4.Repeattheprocedureforeachsectionpivot.
41
