Controls
g204239
Figure7
1.InfoCenter
6.Rangeselector11.Hose-reel-rewindbutton
(optional)
16.Supervisor(rate-lockout)
switch
2.Foam-markerswitch
(optional)
7.Choke
12.Agitationswitch17.Mastersectionswitch
3.Pressuregauge8.Headlightswitch
13.Spray-pressureswitch18.Boom-sectionliftswitches
4.Engineswitch
9.Differentiallock14.Spray-pumpswitch19.Throttle/speedlockswitch
5.Left,center,andright
sectionswitches
10.Sonic-boomswitch
(optional)
15.Rinse-tankswitch(optional)
18
