Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
Weightwithstandardspray
system,empty,without
operator
953kg(2,100lb)
Weightwithstandardspray
system,full,withoutoperator
1678kg(3,700lb)
Maximumgrossvehicleweight
(GVW)(onlevelground)
1814kg(4,000lb)
Overalllengthwithstandard
spraysystem
343cm(135inches)
Overallheightwithstandard
spraysystem
191cm(75inches)
Overallheightwithstandard
spraysystemtothetopof
thesectionsstoredintheX
position
246cm(97inches)
Overallwidthwithstandard
spraysystemsectionsstored
inthe‘X’position
178cm(70inches)
Groundclearance14cm(5.5inches)
Wheelbase
155cm(61inches)
Tankcapacity(includesthe
CE5%overow)
662L(175USgallons)
Attachments/Accessories
AselectionofToroapprovedattachmentsand
accessoriesisavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributor.
Tobestprotectyourinvestmentandmaintainoptimal
performanceofyourT oroequipment,countonToro
genuineparts.Whenitcomestoreliability,T oro
deliversreplacementpartsdesignedtotheexact
engineeringspecicationofourequipment.Forpeace
ofmind,insistonTorogenuineparts.
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
SafetyFirst
Pleasecarefullyreadallofthesafetyinstructionsand
decalsinthesafetysection.Knowingthisinformation
couldhelpyouorbystandersavoidinjury.
PreparingtoDrivethe
Machine
CheckingtheEngineOil
Theengineisshippedwithoilinthecrankcase;
however,thelevelofoilmustbecheckedbeforeyou
rststarttheengineandafteryouhaverunit.
1.Positionthemachineonalevelsurface.
2.Removethedipstickandwipeitwithacleanrag
(Figure11).
3.Insertthedipstickintothetubeandmakesure
thatitisseatedfully.Removethedipstickand
checktheoillevel.
g023037
Figure11
1.Fillercap2.Dipstick
4.Iftheoillevelislow,removethellercapfrom
thevalvecover(Figure11)andpouroilintothe
openinguntiltheoillevelisuptotheFULLmark
onthedipstick;refertoServicingtheEngineOil
(page43)fortheproperoiltypeandviscosity.
Note:Addtheoilslowlyandcheckthelevel
oftenduringthisprocess.Donotoverll.
5.Installthedipstickrmlyinplace.
22
