pressurereadingonthegaugeis6.9bar(100
psi).
g028049
Figure20
1.Agitation-bypassvalve2.Master-sectionbypass
12.PressthepumpswitchtotheOFFposition,shift
thethrottlelevertotheIDLEposition,andturn
theignitionswitchtotheOFFposition.
Adjustingthe
Master-Section-Bypass
Valve
Note:Adjustingthemaster-section-bypassvalve
reducesorincreasestheamountofowsenttothe
agitationnozzlesinthetankwhenthemaster-section
switchissettotheOFFposition.
1.Fillthesprayertank1/2fullwithcleanwater.
2.Movethemachinetoanopenlevelsurface.
3.Settheparkingbrake.
4.SettherangeselectortotheNEUTRALposition.
5.SetthepumpswitchtotheONposition.
6.SettheagitationswitchtotheONposition.
7.Setthemaster-sectionswitchtotheOFF
position.
8.Increasetheenginespeedtofullthrottleandset
thethrottlelocktotheONposition.
9.Adjustthemaster-section-bypasshandleto
controltheamountofagitationoccurringinthe
tank(Figure20).
10.Reducethethrottlespeedtoidle.
11.Settheagitationswitchandpumpswitchtothe
OFFposition.
12.Shutoffthemachine.
LocatingtheSprayPump
Thespraypumpislocatedundertheseat(Figure21).
g216323
Figure21
HaulingtheMachine
•Usefull-widthrampsforloadingthemachineonto
atrailerortruck.
•Tiethemachinedownsecurely.
TransportingtheSprayer
Whenmovingthesprayerlongdistances,useatrailer.
•Securethesprayertothetrailer.
–Usethetie-downloopatthefrontoftheframe;
refertoFigure22A.
–Usethe2tie-downloopsattherearofthe
frame;refertoFigure22B.
•Ensurethattheouter-boomsectionsaretieddown
andsecure.
33
