ElectricalSystem
Maintenance
LocatingtheFuses
Thereare2fuseblocksand1emptyslotinthe
electricalsystem.Theyarelocatedbeneaththeseat
(Figure43).
g023046
Figure43
1.Battery
2.Fuseblocks
ServicingtheBattery
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandlead
compounds,chemicalsknownto
theStateofCaliforniatocause
cancerandreproductiveharm.Wash
handsafterhandling.
Important:Donotjumpstartthesprayer.
Alwayskeepthebatterycleanandfullycharged.Use
apapertoweltocleanthebatteryandbatterybox.If
thebatteryterminalsarecorroded,cleanthemwith
asolutionof4partswaterand1partbakingsoda.
Applyalightcoatingofgreasetothebatteryterminals
topreventcorrosion.
Voltage:12Vwith280coldcrankingAat0°F
RemovingtheBattery
1.Positionthesprayeronalevelsurface,engage
theparkingbrake,shutoffthesprayerpump,
shutofftheengine,andremovethekey.
2.Thebatteryislocatedontherightsideofthe
machinebehindthepump(Figure43).
3.Disconnectthenegative(black)groundcable
fromthebatterypost.
WARNING
Incorrectbattery-cableroutingcould
damagethesprayerandcablescausing
sparks.Sparkscancausethebattery
gassestoexplode,resultinginpersonal
injury.
•Alwaysdisconnectthenegative
(black)batterycablebefore
disconnectingthepositive(red)
cable.
•Alwaysconnectthepositive(red)
batterycablebeforeconnectingthe
negative(black)cable.
WARNING
Batteryterminalsormetaltoolscould
shortagainstmetalsprayercomponents
causingsparks.Sparkscancausethe
batterygassestoexplode,resultingin
personalinjury.
•Whenremovingorinstallingthe
battery,donotallowthebattery
terminalstotouchanymetalpartsof
thesprayer.
•Donotallowmetaltoolstoshort
betweenthebatteryterminalsand
metalpartsofthesprayer.
•Alwayskeepthebatterystrapinplace
toprotectandsecurethebattery.
4.Disconnectthepositive(red)cablefromthe
batterypost.
5.Removethebatteryretainerandfasteners
(Figure43).
6.Removethebattery.
InstallingtheBattery
ServiceInterval:Every50hours—Checkthe
battery-cableconnections.
1.Setthebatteryonthebatteryboxsothatthe
batterypostsaretowardthefrontofthesprayer.
2.Installthebatteryretainerandsecureitwiththe
fastenersyouremovedpreviously(Figure43).
47
