Description
Figure 15
Reference
Dimension or W eight
Height with roll bar raised
E
193 cm (76 inches)
Height with roll bar lowered
G 151 cm (59-1/2 inches)
Overall length
D
271 cm (106-3/4 inches)
Overall width
B
121 cm (47-1/2 inches)
Wheel-base length
C 1 10 cm (43-1/2 inches)
Front-wheel tread width
A
1 14 cm (44-7/8 inches)
Rear-wheel tread width
F
97 cm (38-1/4 inches)
Ground clearance 12 cm (4-3/4 inches)
Net weight (with cutting unit) 630 kg (1389 lb)
Net weight (without cutting unit) 530 kg (1 169 lb)
Speed 0 to 13 km/h (0 to 8 mph)
Cutting width 1 13 cm (44-1/2 inches)
Attachments/Accessories
A selection of T oro approved attachments and accessories is available for use with the machine to enhance
and expand its capabilities. Contact your Authorized Service Dealer or authorized T oro distributor or go to
www .T oro.com for a list of all approved attachments and accessories.
Use only genuine T oro replacement parts and accessories. Replacement parts and accessories made by other
manufacturers could be dangerous, and such use could void the product warranty .
23
