Toro reelmaster 5410 series - Backlapping

Backlapping
DANGER
ToAvoidPersonalInjuryorDeath
•Neverplacehandsorfeetinthereelareawhiletheengineis
running.Stayawayfromthecuttingreelswhenbacklapping.
•Whenbacklapping,runengineatidlespeedonly.
•Whilebacklapping,thereelsmaystallandthenrestart.
•Donotattempttorestartreelsbyhandorfoot.
•Donotadjustreelswhiletheengineisrunning.
•Ifareelstalls,stopenginebeforeattemptingtoclearthereel.
•Reelmotorsareconnectedinseries:rotatingonemotorcauses
rotationinothermotors.
InstructionsandproceduresonbacklappingareavailableintheTractionUnit
Operator'sManualandtheT oroGeneralServiceTrainingBook,ReelMower
Basics(partno.09168SL).
g251598
Figure330
1.T opsurface
3.T opangle
2.Removeburr(withoutdullingsharpcorner)
4.Frontangle
Forabettercuttingedge,runaleacrossthefrontfaceofthebedknifewhenthe
lappingoperationiscompleted.Thiswillremoveanyburrsorroughedgesthat
mayhavebuiltuponthecuttingedge.
Reelmaster
®
5410/5510/5610Series
Page9–19
CuttingUnit:ServiceandRepairs
15216SLRevC
