ReplacingtheHydraulicFilter
ServiceInterval:Every1,000hours—Ifyouare
usingtherecommendedhydraulic
uid,replacethehydrauliclter.
Important:Useofanyotherltermayvoidthe
warrantyonsomecomponents.
1.Parkthemachineonalevelsurface,shutoffthe
engine,engagetheparkingbrake,andremove
thekey.
2.Cleantheareaaroundlter-mountingarea
(Figure81).
g025557
Figure81
1.Filteradapter
2.Hydrauliclter
3.Placeadrainpanunderthelter(Figure81).
4.Removethelterbyrotatingitcounterclockwise
(Figure81).
5.Cleanthelter-seatingsurfaceofthelter
adapter(Figure81).
6.Lubricatethegasketonthenewlterwiththe
speciedhydraulicuid.
7.Threadthelterontothelteradapteruntilthe
gasketoftheltercontactstheseatingsurface
oftheadapter(Figure81),andthentightenthe
lteranadditional1/2turn(Figure81).
8.Starttheengineandletitrunforabout2minutes
topurgeairfromthesystem.
9.Shutofftheengineandcheckthehydraulic-uid
levelinthehydraulictankandthelterareafor
leaks.
ChangingtheHydraulicFluid
ServiceInterval:Every2,000hours—Ifyouare
usingtherecommendedhydraulic
uid,changethehydraulicuid.
Every800hours—Ifyouarenotusingthe
recommendedhydraulicuidorhaveeverlled
thereservoirwithanalternativeuid,replace
thehydraulicuidandlter.
Hydraulic-uidcapacityforNon-TCmodel:7.5L
(2USgallons)
Hydraulic-uidcapacityforNon-TCmodelwiththe
HighFlowHydraulicKit(optional)orTCmodel:
15.1L(4USgallons)
1.Parkthemachineonalevelsurface,shutoffthe
engine,engagetheparkingbrake,andremove
thekey.
2.Raisethecargobed.
3.Removethecapanddipstickfromthellerneck
ofthehydraulictank(Figure82).
g025578
Figure82
1.Cap4.Siphonequipment
2.Dipstick
5.Collectioncontainer
3.Fillerneck(hydraulictank)
4.Routetheintakehoseofthesiphoning
equipmentthroughthellerneckofthehydraulic
tankandtothebottomofthetank(Figure82).
5.Directthedischargehoseofthesiphoning
equipmentintoacollectioncontainer(Figure82)
witha11.4L(3USgallon)capacity—Non-TC
modelor18.9L(5USgallon)capacity—Non-TC
61
