1. PRODUCT OVERVIEW ENGLISH VERSION
1.1 Introduction
E1- 1
1. PRODUCT OVERVIEW
1.1 Introduction
1.2 Features
1.3 Unpacking
T
hank you for choosing the TOSHIBA B-EX6T series bar code printer.
This Owner’s Manual contains from general set-up through to how to
c
onfirm the printer operation using a test print, and should be read carefully
to help gain maximum performance and life from your printer. For most
queries please refer to this manual and keep it safe for future reference.
Please contact your TOSHIBA TEC representative for further information
concerning this manual.
T
his printer has the following features:
• The print head block can be opened enabling easy loading of media
and ribbon.
• Various types of media can be used as the media sensors can be
moved from the centre to the left edge of the media.
• Web based functions such as remote maintenance and other advanced
network features are available.
• Superior hardware, including the specially developed 8 dots/mm (203
dots/inch) or 12 dots/mm (305 dots/inch) thermal print head which
will allow very clear print at a printing speed of 3, 5, 8, 10 or 12
inches/sec.
B-EX6T1/T3-TS/GS12
305dpi/203dpi
3ips
5ips
8ips
10ips
12ips
• Comes with USB I/F, LAN I/F, the RTC/USB host I/F card,
Ribbon Save Module (for Type 1)
Besides the optional Cutter Module, there is also an optional Peel
off Module, Fanfold paper guide, RS-232C I/F card, Centronics
I/F card, Expansion I/O Card, Wireless LAN I/F card, and RFID
module
Unpack the printer as per the Unpacking Instructions supplied with the
printer.
1. Check for damage or
scratches on the printer.
However, please note that
TOSHIBA TEC shall have
no liability for any damage
of any kind sustained during
transportation of the
product.
2. Keep the cartons and
internal packing for future
transportation of the
printer.
To Next Page
