6. PRINTER SPECIFICATIONS ENGLISH VERSION
6. PRINTER SPECIFICATIONS
E6- 1
6. PRINTER SPECIFICATIONS
This section describes the printer specifications.
Model
Item
B-EX6T1/T3-GS B-EX6T1/T3-TS
Destination QM: World wide
B-EX6T1/T3-GS12-QM-R B-EX6T1/T3-TS12-QM-R
CN: China B-EX6T1/T3-GS12-CN-R B-EX4T1/T3-TS12-CN-R
Dimension (W x D x H) 331 mm x 460 mm x 310 mm
Weight (kg) 20 kg
Operating temperature range 5 degC to 40 degC (40 degF to 104 degF)
Relative humidity 25% to 85% RH (no condensation)
Power supply Universal switching power source AC 100 V to 240 V, 50/60 Hz +/- 10%
Input voltage AC100 V to 240 V, 50/60 Hz +/- 10%
Power
Consumption
During a print job*
210W 2.4A - 0.95A
During stand-by 15W or less
During sleep mode
5.7W 0.09A
Resolution 8 dots/mm (203 dpi) 12 dots/mm (305 dpi)
Printing method Thermal transfer or Direct Transfer
Printing speed 76.2 mm/sec. (3 inches/sec.)
127.0 mm/sec. (5 inches/sec.)
203.0 mm/sec. (8 inches/sec.)
254.0 mm/sec. (10 inches/sec.)
304.8 mm/sec. (12 inches/sec.)
Available media width (including
backing paper)
50mm to 165mm
Effective print width (max.) 160.0 mm (203DPI), 159.9 mm (305DPI)
Issue mode Batch
Peel Off (Strip mode is enabled only when the optional Strip Module is
installed.)
Cut (Cut mode is enabled only when the optional Cutter Module is
installed.)
LCD Message display Graphic type 128 x 64 dots or more, with back light
*: While 15% slant lines are printed in the specified format.
To Next Page
