7. SUPPLY SPECIFICATIONS ENGLISH VERSION EO1-33089
7.2 Ribbon
E7-6
7.2 Ribbon
Please make sure that the ribbon being used is approved by TOSHIBA TEC. The warranty does not apply to any
problem caused by using non-approved ribbons.
For information regarding TOSHIBA TEC approved ribbon, please contact a TOSHIBA TEC service
representative.
B-EX6T Type1
B-EX6T Type3
Ribbon Width 55mm to 170mm
Max Ribbon Length
600m
*Using AG6E ribbon:800m.
Max Ribbon OD
φ90mm
Ribbon Core Inside 25.7± 0.2mm
Type Ribbon for edge head
Ribbon for flat head
Ribbon winding
Outside Outside and Inside
The table below shows the correlation between ribbon width and media width (backing paper is not included.)
Ribbon width Media width Ribbon width Media width Ribbon width Media width
55 mm 50 mm 102 mm 80 – 97 mm 170 mm 130 – 165 mm
68 mm 51 – 63 mm 112 mm 98 – 107 mm
76 mm 64 – 63 mm 114 mm 98 – 109 mm
84 mm 64 – 79 mm 134 mm 108 – 129 mm
7.3 Recommended Media and Ribbon Types
Media type De
scription
Vellum paper and labels General use for low cost applications.
Coated paper
General use including applications that require small letters and/or symbols.
Glossy coated paper
Used where a high-grade finish is required
Plastic films
This water-proof and solvent-resistant material has high physical strength
and low-temperature resistance, but poor heat resistance (dependant upon
material). This material can be used for labels stuck to recyclable
containers, so it can be recycled in the same process.
PET film
This water-proof and solvent-resistant material has high physical strength,
and low-temperature resistance as well as heat resistance. This material is
used for many applications, especially where high durability is required.
Mode/serial plate labels, caution labels, etc.
Polyimide
This material gives the best performance on heat resistance (greater than
PET film). It is often used for PCB labels as it can withstand passage
through a solder bath.
NOTES:
1. To ensure print quality and print head life use only TOSHIBA TEC specified ribbons.
2. To avoid ribbon wrinkles use a ribbon that is wider than the media by 5 mm or more. However, too much
difference in width between the two may cause wrinkles.
