1. PRODUCT OVERVIEW ENGLISH VERSION
1.5 Appearance
E1- 3
1.5 Appearance
1.5.1 Dimensions
1.5.2 Front View
1.5.3 Rear View
The names of the parts or units introduced in this section are used in the
following chapters.
Dimensions in mm (inches)
(12.2)
Top Cover
Media Outlet
Supply Window
LCD Message Display
Operation Panel
For GS/TS12 and GS/TS18 models,
Reserved for Serial Interface.
For GS/TS16 models, WLAN
Interface
LAN Interface
AC Power Inlet
Reserved for Expansion I/O
interface
Reserved for Parallel Interface
USB Interface
Power Switch
Cover for USB
USB Bluetooth dongle
Connect Smart device (Mobile phone)
for Parameter setting
USB memory
Install firmware/ to copy log data
Standard USB Host I/F for
USB memory or USB Bluetooth
