2. PRINTER SETUP ENGLISH VERSION
2.3 Loading Supplies
E2-11
2.3.2 Loading the Ribbon
(Cont.)
3. Slide the Ribbon Stoppers along the Ribbon Shafts so that the ribbon
will be centered when fitted.
4. Lower the Print Head Block and set the Print Head Block Holder
Plate .
5. Take up any slack in the ribbon. Wind the leading tape onto the
ribbon take-up roll until the ink ribbon can be seen from the front of
the printer.
6. Turn the Head Lever to Lock position to close the Print Head.
7. Close the Top Cover.
Auto Ribbon Saving Mode
B-EX6T1 has a ribbon saving function, it is possible to reduce ribbon
waste by stopping the ribbon feed for non-print areas. To activate the
ribbon save a minimum non-print area is required as below.
203 & 305 dpi models
Print speed 3
ips
5 ips
8 ips
10 ips
12 ips
Min. non-print area 20 20 25 35 60
Print Head Holder
Bl
ock Plate
(mm)
To Next Page
