7. SUPPLY SPECIFICATIONS ENGLISH VERSION
7.1 Media
E7-2
Max. outer roll diameter Φ200mm
Thickness
Label 0.13 to
0.17mm
Tag 0.15 to
0.25mm
Label 0.13 to
0.17mm
Tag 0.15 to
0.17mm
Label 0.13 to
0.17mm
Roll-up method
Inner ・Outer
Paper core ID φ76.2±0.3mm
NOTES:
1. To ensure print quality and print head life use only TOSHIBA TEC specified media.
2. When using the peel-off at 12”/sec or more for 203dpi model, issue at 10”/sec.
When using the peel-off at 10”/sec or more for 305dpi model, issue at 8”/sec.
3. When the Disc cutter is used, the minimum label length shall be 18.0 mm – (Gap length/2) or longer.
4. The ratio of a label length to a gap length must be a minimum of 3 to 1 (3:1).
5. When using label stock in cut mode, be sure to cut in the gaps. Cutting labels will cause the adhesive to stick to
the cutter, which may affect the cutter performance and shorten the cutter life.
