e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE AND TROUBLESHOOTING
6 - 10
CB90 Finisher related
service call
Paper pushing plate motor abnormality: Paper
pushing plate motor is not rotating or paper pushing
plate is not moving normally. [MJ-1030]
P. 6-77
CBA0 Stitch motor (front) abnormality: Stitch motor (front)
is not rotating or rotary cam is not moving normally.
[MJ-1030]
P. 6-77
CBB0 Stitch motor (rear) abnormality: Stitch motor (rear)
is not rotating or rotary cam is not moving normally.
[MJ-1030]
P. 6-77
CBC0 Alignment motor abnormality: Alignment motor is
not rotating or aligning plate is not moving normally.
[MJ-1030]
P. 6-77
CBD0 Guide motor abnormality: Guide motor is not
rotating or guide is not moving normally. [MJ-1030]
P. 6-77
CBE0 Paper folding motor abnormality: Paper folding
motor or paper folding roller is not rotating normally.
[MJ-1030]
P. 6-78
CBF0 Paper positioning plate motor abnormality: Paper
positioning plate motor is not rotating or paper
positioning plate is not moving normally. [MJ-1030]
P. 6-78
CC00 Sensor connector abnormality: Connector of guide
home position sensor, paper pushing plate home
position sensor or paper pushing plate top position
sensor is disconnected. [MJ-1030]
P. 6-78
CC10 Micro switch abnormality: With all covers closed,
inlet door switch, delivery door switch or front cover
switch is open. [MJ-1030]
P. 6-79
CC20 Communication error between finisher and saddle
stitcher: Communication error between finisher
controller PC board and saddle stitcher controller
board [MJ-1030]
P. 6-79
CC30 Stack transport motor abnormality: The stack
transport motor is not rotating or the stack transport
belt is not moving normally. [MJ-1101]
Stack delivery motor abnormality: The stack
delivery motor is not rotating normally. [MJ-1031]
P. 6-79
CC31 Transport motor abnormality: The transport motor is
not rotating or the stack transport roller -1 and -2 is
not rotating normally. [MJ-1101]
P. 6-80
CC40 Swing motor abnormality: Swing motor is not
rotating or swing unit is not moving normally. [MJ-
1030]
P. 6-80
CC41 Paper holder cam home position abnormality: The
paper holder cam is not at the home position. [MJ-
1101]
P. 6-80
CC50 Finisher related
service call
Horizontal registration motor abnormality:
Horizontal registration motor is not rotating or
puncher is not shifting normally. [MJ-1030 (when
MJ-6004 is installed)]
P. 6-81
CC51 Sideways adjustment motor (M2) abnormality:
Sideways adjustment motor is not rotating or
puncher is not shifting normally. [MJ-1101 (when
MJ-6101 is installed)]
P. 6-81
CC52 Skew adjustment motor (M1) abnormality: Skew
adjustment motor is not rotating or puncher is not
shifting normally. [MJ-1101 (when MJ-6101 is
installed)]
P. 6-82
Error code Classification Contents Troubleshooting
