OPERATOR’S MANUAL
series Robot Controller
Press the EXE key, and the position name is replaced by the newly specified
name. The following display appears.
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 5 5 5 5 5 = 3 0 0 , 300 , 3 00 ,
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
↓
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
3 0 0 . 1 2 3 w / . w o r l d
S A V E P R G F U L L T R A N S P Y L D >
(3) Cautions
• The main cursor moves to the X data area.
• If the input name is illegal, a message saying "ILLEGAL NAME" is displayed
on the command line and no data is changed. Press any key, and the
system returns to the name editing mode.
• If the specified name already exists, a message of "DUPLICATE NAME" is
displayed on the command line and no data is changed. Press any key, and
the system returns to the name editing mode.
STE 80720
– 5-9 –
