I
NTRODUCTION —
How to Use This Manual
IN-3
Illustration:
what to do and where
The procedures are presented in a step-by-step format:
•
The illustration shows
what
to do and
where
to do it.
•
The task heading tells
what to do.
•
The detailed text tells
how
to perform the task and gives
other information, such as specifications and warnings.
Example:
Task heading: what to do
3.
INSTALL FUEL PUMP BRACKET TO FUEL TANK
(a) Install a new gasket and the pump bracket with the
screws.
Torque: 35 kg-cm (30 in.-lb, 3.4 N•m)
Detailed text:
how to do task
This format provides the experienced technician with a FAST
TRACK to the information needed. The upper case task head-
ing can be read at a glance when necessary, and the text
below it provides detailed information. Important specifica-
tions and warnings always stand out in bold type.
Torque Specification
1
REFERENCES
References have been kept to a minimum. However, when
they are required you are given the page to refer to.
SPECIFICATIONS
Specifications are presented in bold type throughout the text
where needed. You never have to leave the procedure to look
up your specifications. They are also found in Appendix A, for
quick reference.
CAUTIONS, NOTICES, HINTS
•
CAUTIONS are presented in bold type, and indicate there is
a possibility of injury to you or other people.
•
NOTICES are also presented in bold type, and indicate
there is a possibility of damage to the components being
repaired.
•
HINTS are separated from the text but do not appear in
bold. They provide additional information to help you per-
form the repair more efficiently.
