96
You can leave it blank if the Internal Port is the same as the Service Port, or enter a specific
port number when Se rvice Port is a single one.
Protocol: The protocol used for this application, either TCP, UDP, or All (all protocols
supported by the modem router).
Status: The status of this entry, "Enabled" means the virtual server entry is enabled.
WAN: The WAN Service Interface providing the service application.
Edit: To modify or delete an existing entry.
To se t up a virtual server entry:
1. Click the Add New button. (pop-up
Figure 4-93)
2. Select the service you want to use from the Common Se rvice Port list. If the Common
Service Port menu does not list the service that you want to use, enter the number of the
service port or service port range in the Service Port field.
3. Enter the IP address of the computer running the service application in the IP Address field.
4. Select the protocol used for this application in the Protocol drop-down list, either TCP, UDP,
or All.
5. Select the Enabled option in the Status drop-down list.
Click the Sav e button.
Figure 4-93
Note:
It is possible that you have a computer or server that has more than one type of available service.
If so, select another service, and type the same IP address for that computer or server.
To modify or delete an existing entry:
1. Find the desired entry in the table.
2. Click Edit as desired on the Edit column.
Click the Enable/ Disabled Selected button to make selected entries enabled/ disabled.
Click the Delete Selected button to delete selected entries.
Note:
If you set the service port of the virtual server as 80, you must set the Web management port on
System Tools –> Manage Control page to be any other value except 80 such as 8080.
