TP-Link TD-VG5612 User Manual

TD-VG5612
300Mbps Wireless N VoIP VDSL/ADSL Modem Router User Guide
133
Appendix C: Telephony Features
This section introduces what the following features are used for.
Call Holding
This feature allows you to put a call on hold, in which case the call is not ended but no verbal
communication is available.
To put a call on hold, press the FLASH button. To return to the original call, press the FLASH
button again.
Call Transfer
This feature allows you to redirect the current call to another phone by using the F LASH button
and dialing the destination number.
To transfer a call, please follow the steps below:
1. Press F LASH button to put the current call on hold.
2. Dial the destination number.
Note: To quit the transfer, press the FLASH button again to return to the original call before
hearing the ringback tone.
3. Hang up when hearing the ringback tone or wait for the newly called party to answer and then
hang up. Now the call is successfully transferred.
Call Waiting
With this feature enabled, if a calling party places a call to you while you are busy, you are able to
suspend the current call and switch to the new incoming call.
To switch to the new incoming call, press FLASH followed by the number 2. The first call will be
automatically put on hold. You can switch between the two calls by pressing F LASH followed by
the number 2.
USB Voice M ail
With this feature enabled, the caller will be prompted to leave a voice message upon the call or
when there is no response for a certain time.
Call Forwarding
This feature allows an incoming call to be redirected to a specified party. There are two call
forwarding features, including Call Forwarding Unconditionally and Call Forwarding on No Answer.
 With Call Forwarding Unconditionally enabled, no matter whether the called party is busy or
not, the incoming call will be redirected to the specified party.
 With Call Forwarding on No Answer enabled, the incoming call will be redirected to the
specified party when there is no response for a certain time.
Anonymous Calling
This feature allows you to make a call without your phone number or ID being displayed on the
called party's phone.
Anonymous Call Blocking
With this feature enabled, all anonymous calls will be blocked.

TP-Link TD-VG5612 Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	Yes
Frequency range	2.4 - 2.4835 GHz
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antenna type	Internal
Antennas quantity	2
Antenna gain level (max)	2.6 dBi
Routing protocols	RIP-1, RIP-2
USB version	2.0
RS-232 ports	0
USB ports quantity	1
Memory card slot(s)	-
RJ-11 ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	LAN (RJ-45), Phone (RJ-11)
Certification	RoHS, RCM
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Product color	White
Power source type	AC
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s

Weight and Dimensions

Depth	60 mm
Width	174 mm
Height	130 mm
Weight	- g
