Note:
1) To use the DHCP server function of the modem router, you must configure all computers on
the LAN as "Obtain an IP Address automatically".
2) You have to disable NAT of the WAN connections, or the DHCP Relay may not take effect.
3) If you select Disabled, the DHCP function will not take effect.
Click the Save button to save your settings.
4.7.2 Clients List
Choose menu “DHCP Server”“Clie nts List”, you can view the information about the clients
attached to the modem router in the screen as shown in Figure 4-39.
Figure 4-39
Client Name: The name of the DHCP client
M AC Ad dr e ss: The MAC address of the DHCP client
IP Address: The IP address that the modem router has allocated to the DHCP client
Valid Time : The time of the DHCP client leased. After the dynamic IP address has expired, a
new dynamic IP address will be automatically assigned to the user.
To update this page and to show the current wireless devices, click the Refresh button.
4.7.3 Address Reservation
Choose menu “DHCP Server”“Address Reservation”, you can view and add a reserved
address for clients via the next screen (shown in Figure 4-40).When you specify a reserved IP
address for a PC on the LAN, that PC will always receive the same IP address each time when it
accesses the DHCP server. Reserved IP addresses should be assigned to the servers that require
permanent IP settings.
Figure 4-40
M AC Address: The MAC address of the PC for which you want to reserve an IP address.
IP Address: The IP address reserved for the PC by the modem router.
Status: The status of this entry either Enabled or Disabled.
To Reserve an IP address:
1. Click the Add New button. Then Figure 4-41 will pop up.
2. Enter the MAC address (in XX:XX:XX:XX:XX:XX format.) and IP address (in dotted-decimal
To Next Page
