TD-VG5612
300Mbps Wireless N VoIP VDSL/ADSL Modem Router User Guide
106
4.17.1 IPv6 Rule
Choose menu IPv 6 Firewall
IPv6 Rule, and then you can view and set Access Control
rules in the screen as shown in Figure 4-108.
Figure 4-108
Enable IPv 6 Firewall: Select the check box to enable the IPv6 Firewall function, so the
Default Filtering Rules can take effect.
Description: Here displays the description of the IPv6 rule and this name is unique.
IPv 6 LAN Host: Here displays the LAN host selected in the corresponding rule.
IPv 6 WAN Host: Here displays the WAN host selected in the corresponding rule.
Schedule: Here displays the schedule selected in the corresponding rule.
Status: Here displays the status of the rule either enabled or disabled.
Edit: Here you can edit or delete an existing rule.
To add a new IPv 6 rule:
1. Click the Add New button, and you will see the screen as shown in Figure 4-109.
Figure 4-109
2. Give a name (e.g. Rule_1) for the rule in the Description field.
