Func. Name Descriptions
Range of
Setting
Unit
Factory
Setting
Note
F1.05 Reserved Reserved
─ ─ ─
*Note
9
F1.06
Frequency
Command
Selection
(operation
panel)
0: In the monitor mode, frequency
command cannot be changed.
1: In the monitor mode, frequency
command is changeable.
0, 1 ─ 1
*Note
9
F1.07
Reserved
Reserved
─ ─ ─
*Note
9
F1.08
Main Display
Selection
Control panel have 8 display option
1: Output frequency
2: Frequency command
3: Output voltage
4: DC bus voltage
5: Output current
6: Terminal status
7: Temperature of heat sink
8: Display mode 8 (F1.11)
1~8 ─ 1
F1.09 Reserved
─ ─ ─
*Note
9
F1.10 Reserved
─ ─ ─
*Note
9
F1.11
Display
Mode 8
0: Terminal status
1: Temperature of heat sink
2: Motor rotation speed(RPM)
3: Machine speed(MPM)
4: The sector of sequential operation
control
5: The cycle of sequential operation
control
6: Counting value
7: Current limit level
8: Primary frequency command
9: Secondary frequency command
10: PID command
11: PID feedback
0~11 ─ 2
*Note
9
F1.12 Reserved Reserved
─ ─ ─
*Note
9
F1.13
Machine
Speed Ratio
Set the ratio of machine speed. This
function determines MPM display
value.
0.00~500.00 0.01 20.00
F1.14
Digits of
Decimal
Value
(Machine
Speed)
Select the digits of decimal values
displaying the machine speed.
0~3 ─ 0
The color as means functions can be set during the operation.
22
