Func. Name Descriptions
Range of
Setting
Unit
Factory
Setting
Note
F5.19
Multi-function
Input
Terminal X1
-28 ~ +28
*Note 7
─ 22
F5.20
Multi-function
Input
Terminal X2
-28 ~ +28
*Note 7
─ 23
F5.21
Multi-function
Input
Terminal X3
0: Disable
±1: Jog command
±2: Secondary accel/decel command
switching
±3: Multi-speed level 1 command
±4: Multi-speed level 2 command
±5: Multi-speed level 3 command
±6: reserved
±7: Reset command
±8: External fault command(EF)
±9: Interruption of output command(bb)
±10: Coast to stop command(Fr)
±11: Speed search from the maximum
frequency
±12: Speed search from the frequency
±13: Holding command
±14: UP command
±15: DOWN command
±16: Clean UP/DOWN frequency
command
±17: UP/DOWN command enter key
±18: Analog input source selection
(Pot knob/AI)
±19: Primary and secondary
frequency command option
±20: Start command of sequential
operation control
±21: Pause command of sequential
operation control
±22: Forward command
±23: Reverse command
±24: Stop command with 3-wire
start/stop circuit
±25: DC braking enable (Stop)
±26: Counter input
±27: Counter clear
±28: Current limit enable
-28 ~ +28
*Note 7
─ 1
F5.25
Digital Input
Response
Time
When the input signal is under the
setting time, program will not be
activated.
1~255 1ms 10
*Note 9
The color as means functions can be set during the operation.
