b. F1.01 = 1
The frequency command can be set by function F2.00 using operation panel and
by
▼
key in the monitor mode as well.
c. F1.01 = 3
MPM command is set using the operation panel.
d. F1.01 = 4
UP/DOWN command control.
Selection by multi-function input terminal X1~X4(UP command, DOWN command,
Clear the frequency command by UP/DOWN, Confirm the frequency command
by UP/DOWN).
e. F1.01 = 5
Frequency command is set by communication control.
※ F1.01 = 1~3
Press
or key one time in the monitor mode. The value of the frequency
command in the panel display will be blinking but not changed. Press
or
▼
key again to change frequency command.
【F1.02】 Secondary Frequency Command Selection
Set functions F5.19~F5.22 as ±19, and switch the primary/secondary frequency
command by multi-function input terminals.
The settings are listed as the following: (see the parameter description of F1.01)
0: Analog input setting
1: Operation panel setting
2: UP/DOWN setting
【F1.03】 Analog Input Selection
The settings are listed as below: (see the parameter description of F5.00~F5.01)
0:
“Pot knob”＋AI
1:
“Pot knob”－AI
2: AI－
“Pot knob”
3:
“Pot knob” or AI (switched by multi-function input terminals)
4:
“Pot knob”
5: AI
※
“Pot knob” is on the operation panel, and AI is the analog input terminal.
【F1.04】“Pot knob” Command Source Selection
The settings are listed as below:
0: From drive’s operation panel.
1: From external keypad (KP-601).
43
